SPECIFICATION (All the parameters are measured under
230VAC input,more than 10% of rated load,and 25℃ of ambient temperature)

ItemSpecifications
Output Voltage Selectable5V;12V;24V
Overload protectionBuilt-in
Short circuit protectionHiccup mode, recovers automatically after fault condition is removed
Over voltage protectionBuilt-in
Withstand voltageIP-OP:3000Vac; IP-PE:1500Vac;OP-PE:500vdc
Working temperature-40~70℃
Start-up Time<3Sec
Safety standardsGB4943/EN60950
EMCstandardsIEC61000-4
Connection9.5mm screw terminial
Dimension(L*W*H)160±1mm×42±1mm×26±1mm

Model List

FS-400-12ModelInputOutputCurrentR&NEffiTempStorage temperature
FS-60-5AC90-305V5V12A<300mV87%-40-70℃-40℃-85℃
FS-60-12AC90-305V12V5A<300mV88%-40-70℃-40℃-85℃
FS-60-24AC90-305V24V2.5A<300mV87%-40-70℃-40-70℃
