SPECIFICATION (All the parameters are measured under
230VAC input,more than 10% of rated load,and 25℃ of ambient temperature)

ItemSpecifications
Output Voltage Selectable12V;24V
Overload protectionBuilt-in
Short circuit protectionHiccup mode, recovers automatically after fault condition is removed
Over voltage protectionBuilt-in
Withstand voltageIP-OP:3000Vac; IP-PE:1500Vac;OP-PE:500vdc
Working temperature-40~70℃
Start-up Time<3Sec
Safety standardsGB4943/EN60950
EMCstandardsIEC61000-4
Connection9.5mm screw terminial
Dimension(L*W*H)317±1mm×53±1mm×21.5±1mm

Model List

FS-400-12ModelInputOutputCurrentR&NEffiTempStorage temperature
DTA-300-12AC90-305V12V8.3A<300mV86%-40-70℃-40℃-85℃
DTA-300-24AC90-305V24V4.2A<300mV86%-40-70℃-40℃-85℃
